TYZ-CR500 CL Flush-Mount Folding Arm Retractor
Folding arm retractor designed to sit flush with sheet metal, for a cleaner enclosure face. Damped return, 30 kg load and customizable single or dual-section arms.
Flush mounting for a cleaner enclosure
The TYZ-CR500 is designed to sit flush with sheet metal, so the retractor becomes part of the cabinet face rather than an add-on. That suits OEM enclosure builds and any installation where appearance matters alongside function.
Damped, controlled return
The main arm spindle uses a coil spring return with a damping effect, so the arm retracts without a snap. Operation is light — rotational torque stays at or below 3 kg — and the powder-coated finish passes a 720-hour salt spray test.
Where it fits
- OEM and private-label enclosures — retractor built into the cabinet face
Premium public charging — appearance and function together
- Integrated AC/DC cabinets — compact internal packaging
Multi-cable pedestals — single or dual-section arm options
Single or dual-section arm
Main section length runs from 500 to 1000 mm. A 300–500 mm secondary section can be added, with a combined maximum of 1000 mm. Both sections rotate through 180°.
Get a specification sheet
Send us your enclosure drawing and cable specification, and we will confirm the arm configuration and share the specification sheet.
Specifications
Model: TYZ-CR500
Type: Flush-mount folding arm retractor
Max working load: 30 kg
Installation: Flush with sheet metal enclosure
Main arm length (A): 500–1000 mm (customizable)
Secondary arm length (B): 300–500 mm
Total length (A+B): ≤ 1000 mm
Rotation angle: Main section 180° / secondary section 180°Return mechanism: Main arm spindle coil spring with dampingExtrusion profile: 60 × 30 mmMaterial: Aluminium alloySurface finish: Powder coating; no red rust after 720-hour salt sprayOperating torque: ≤ 3 kgService life: Over 150,000 cycles
