Chargers with Display / POS Integration
DC60kW + AC43kW Integrated Charger (Three Connectors)
Integrated AC+DC charger with DC 60kW (CHAdeMO + CCS2) and AC 43kW (Type 2), three connectors, 10.1-inch touchscreen and OCPP 1.6J.
This integrated AC+DC charger combines a 60kW DC fast charger (CHAdeMO + CCS2) with a 43kW AC charge point (Type 2) in one cabinet, covering three connector types on a single footprint.
Key features
DC 60kW with CHAdeMO and CCS2, plus AC 43kW Type 2. 10.1-inch touchscreen, OCPP 1.6J networking, and optional POS payment.
Specifications
Power: DC 60kW + AC 43kW
Number of connectors: Three connectors — DC: CHAdeMO, CCS2; AC: Type 2
Cable length: 5m standard
Display: 10.1-inch touchscreen
Cooling: Air-cooled
Startup method: APP /10%Output current: CHAdeMO 125A; CCS2 200A; AC 63AInput frequency: 45-65HzProtection: Short circuit, overload, over-temperature, leakage, over/under-voltage RFID card / POS (optional)Networking: 4G / WiFi / Ethernet / BluetoothNetwork platform: WS/WSS, OCPP 1.6J (OCPP 2.0 optional)Output voltage: CHAdeMO 150-500V; CCS2 200-1000V; AC 380VInput voltage: AC 400V±
