30-80kW DC Fast Chargers
30-40kW DC Fast Charger
30-40kW air-cooled DC fast charger with 4.3-inch touchscreen, 200-1000V output, 0-125A and OCPP 1.6J. Single-connector compact design.
The 30-40kW DC fast charger provides higher output than the 20-30kW class while staying in a compact single-connector format. It is suited to fleet depots and destination charging.
Key features
30-40kW output, 200-1000V DC, 0-125A, air-cooled, 4.3-inch touchscreen, OCPP 1.6J.
Specifications
Power: 30kW /10%Output current: 0-125AInput frequency: 45-65HzProtection: Short circuit, overload, over-temperature, leakage, over/under-voltage 40kWNumber of connectors: Single connectorCable length: 5m standardDisplay: 4.3-inch touchscreenCooling: Air-cooledStartup method: APP / RFID cardNetworking: 4G / WiFi / Ethernet / BluetoothNetwork platform: WS/WSS, OCPP 1.6J (OCPP 2.0 optional)Output voltage: 200-1000VInput voltage: AC 400V±
