20-40kW DC Fast Charger (7-inch Display)
20-40kW air-cooled DC fast charger with 7-inch touchscreen, 200-1000V, 0-125A and optional POS. Single connector with 208-240V input option.
This DC fast charger class adds a 7-inch touchscreen and an optional POS payment module, with a 20-40kW output range and a North American 208-240V input option.
Key features
20-40kW output, 200-1000V DC, 0-125A, 7-inch touchscreen, optional POS, air-cooled.
Specifications
Power: 20kW /10% (AC 208V-240V optional)Output current: 0-125AInput frequency: 45-65HzProtection: Short circuit, overload, over-temperature, leakage, over/under-voltage 30kW / 40kWNumber of connectors: Single connectorCable length: 5m standardDisplay: 7-inch touchscreenCooling: Air-cooledStartup method: APP / RFID card / POS (optional)Networking: 4G / WiFi / Ethernet / BluetoothNetwork platform: WS/WSS, OCPP 1.6J (OCPP 2.0 optional)Output voltage: 200-1000VInput voltage: AC 400V±
