80-300kW DC Fast Chargers
120-180kW Dual-Connector DC Fast Charger (300A)
120-180kW dual-connector DC fast charger with 10.1-inch touchscreen, 0-250A/0-300A output, 200-1000V and optional POS. High-power public charging.
This version of the 120-180kW DC fast charger raises the output current to 300A, supporting faster charging for vehicles with larger battery packs.
Key features
120-180kW output, two connectors, 200-1000V DC, up to 300A, 10.1-inch touchscreen, optional POS.
Specifications
Power: 120kW /10%Output current: 0-250A / 0-300AInput frequency: 45-65HzProtection: Short circuit, overload, over-temperature, leakage, over/under-voltage 180kWNumber of connectors: Dual connectorCable length: 5m standardDisplay: 10.1-inch touchscreenCooling: Air-cooledStartup method: APP / RFID card / POS (optional)Networking: 4G / WiFi / Ethernet / BluetoothNetwork platform: WS/WSS, OCPP 1.6J (OCPP 2.0 optional)Output voltage: 200-1000VInput voltage: AC 400V±
